Why is my Plate Heat Exchanger Leaking?
Plate heat exchanger leaks can lead to unscheduled plant room downtime, energy inefficiency and potentially dangerous cross-contamination between primary and secondary fluid circuits. Identifying the root cause quickly is essential to keeping operating costs down and restoring system reliability.
Whether you’re noticing external leaking around the frame or an internal pressure drop, here are the 6 most common causes of plate heat exchanger leaks and how to resolve them.
1. Gasket Failure
Over time, elastomeric gaskets can harden, perish, or lose their elasticity due to continuous thermal cycling and exposure to system chemicals. Once the seal is compromised, fluid will escape from the plate pack.
-
The Symptom: External weeping or dripping around the perimeter of the plate pack.
-
The Solution: Replace the gasket set, ensuring you match the original specifications.
2. Pressure Spikes
Sudden surges in pressure can move the plates, momentarily breaking the seal and causing a leak or permanently deforming the gaskets.
-
The Symptom: Intermittent leaks or sudden fluid sprays during pump startup, valve actuation, or boiler ignition.
-
The Solution: Install slow-closing valves, variable speed drives on pumps, or expansion vessels to absorb system pressure surges.
3. Corrosion
If the fluids being used are too aggressive for the plate material, small pinholes can form across the metal surface, leading to internal cross-contamination.
-
The Symptom: Fluid mixing between the primary heating loop and secondary domestic hot water loop, often identified by an unexplained pressure transfer between circuits.
-
The Solution: Perform a light or dye-penetrant test on individual plates to identify compromised units. Replace damaged plates and re-evaluate system water treatment and filtration.
Unsure what’s causing your plate heat exchanger leak?
Our technical team can help diagnose the root cause, verify your plate dimensions and accurately recommend replacement parts
4. Improper Tightening
If the plate pack isn’t tightened to the manufacturer’s specific instructions, the gaskets won’t be compressed enough to create a seal. On the other hand, over-tightening can crush and permanently damage the gaskets and warp the metal plates, resulting in plate heat exchanger leaks.
-
The Symptom: Leaks across the top or bottom of the frame following recent maintenance or plate inspection.
-
The Solution: Use a torque wrench to adjust the tie-bolts evenly, measuring parallel plate distance against the manufacturer’s specified A-dimension.
5. Temperature Fluctuations
Rapid temperature fluctuations cause the metal plates to expand and contract too quickly, which can shift the gaskets out of place or cause temporary seal separation.
-
The Symptom: Temporary leaks during system warm-up or rapid cooling cycles that vanish once operating temperatures stabilise.
-
The Solution: Adjust boiler staging and modulation controls to smooth out rapid temperature ramps and protect gasket seating.
6. Operating Outside Design Parameters
Many older PHEs were designed for specific high operating temperatures. If you’ve upgraded to modern condensing boilers or low-temperature heat pumps that run at lower temperatures, the original plate pack compression and gasket dynamics may no longer perform efficiently or maintain a proper seal.
-
The Symptom: Persistent weeping or poor heat transfer performance following a primary heating plant room upgrade.
-
The Solution: Re-evaluate plate configuration and channel sizing with your technical team to ensure the plate pack is optimised for the new system.
How to Prevent Plate Heat Exchanger Leaks
To extend the lifespan of your equipment and prevent expensive repairs and operating downtime, follow these best practices:
- Schedule Regular Servicing: Routine inspections allow you to catch brittle gaskets or early signs of corrosion.
- Choose Correct Materials and Fluids: Ensure your gaskets and plate materials are compatible with the fluids in your system.
Stick to Design Parameters: It is essential that your plant operates within the specific parameters your PHE was originally built for. - Implement Regular Cleaning: Dirt, debris and scale build-up can cause erosion. Regular cleaning maintains the condition of the plates.
